FlightLine RC Spitfire Mk.IX 1200mm (47 inch) Wingspan PNP Rc Airplane

FlightLine RC Spitfire Mk.IX 1200mm (47 Inch) Wingspan - PNP RC Airplane

Wholesale price: [ $186.00 ]
FlightLineRC Spitfire Mk.IX 1200mm (47 inch) Wingspan PNP Rc Airplane

1,3748-580Kv Brushless Outrunner Motor (Stock scale power system)
2, 6 Channel Radio
3, 6 Channel Receiver

if you want to know wholesale discount price,please contact us by e-mail.

Note:
If your shipment is delivered to a remote area,this charge will be added to your shipping cost.Checking your area is a remote area or is not a remote area on the website:http://remoteareas.dhl.com/jsp/first.jsp

FlightLineRC Spitfire Mk.IX 1200mm (47 inch) Wingspan PNP Rc Airplane Specifications:



The Spitfire also features oversized retracts with metal trunions and metal reinforcing plates,Slightly oversized tires help to minimize nose overs,With the recommended 4s 2650 mAh battery we obtain 5-6 minutes of mixed throttle scale flight,The model can also accommodate an 4s 3000mAh or even 4s 4000mAh battery for longer flight times, but the 2650mAh and 3000mAh are the best balance between speed, vertical power, flight duration, and wing loading

The Freewing 80mm Avanti S recently won first place for "Best Flight" at AEF 2017, so bring an award winner into your hangar today!



Features:

Removable main wing/elevator for easy transport
Split flaps for easier takeoffs and landings
High power motor for stock speeds up to 135kph/83mph
Intuitive internal structural design for optimized cooling of all electronics in the fuselage from the nose to the tail
Large cabin space for easy placement of the battery and radio equipment
Built-in flat spot near the CG for optimal placement of a gyro (optional, sold separately)
Improved spinner and propeller mounting design to enable better balance
Tall foam rubber 65mm diameter main wheels and additional forward rake angle for operating on short grass runways
Electric retractable landing gear with metal trunions, metal reinforcement plate and 4mm steel wire struts
Optional two bladed propeller Sport Power System (sold separately) to achieve speeds up to 150kph/93mph

Attention:

There is an optional two bladed propeller Sport Power System (sold separately) to achieve speeds up to 150kph/93mph. This Sport Power System includes: 3648-880kV motor, 12x8 2 blade propeller, and 2 bladed spinner. This Sport Power System is suitable for all 1100-1200mm wingspan warbirds from the FlightLineRC brand.



Includes:

Requires:

  • Minimum 6 Channel Radio
  • 6 Channel Receiver
  • 4 Cell 14.8V 2650 mAh LiPo Battery with T connector
  • Lipo Battery Charger

Requires:

REQUIRES:
Brushless motor, EDF unit and ESC (see specifications for details)
6 Channel Radio - Select a minimum 6 channel radio
6 Channel Receiver - Select a minimum 6 channel receiver
6 Cell 22.2V 4000 mAh or 5000 mAh LiPo Battery with EC5 connector - We recommend the EPR40006PRO
6 Cell Compatible Battery Charger - Select a minimum 6 cell (6S) charger

PRODUCT SPECIFICATIONS:

Wingspan

1200mm / 47in

Length

1085mm / 42.7in

Flying Weight

1550g / 54oz

CG (Center of Gravity) 80mm from the leading edge of the wing at the root

Power System

3748-580Kv Brushless Outrunner Motor (Stock scale power system)
3648-880Kv Brushless Outrunner Motor (Optional sport power system)

Electronic Speed Control

60A Brushless with T connector

Propeller / EDF

12x7 4 Blade Propeller / 12x8 2 Blade Propeller High Performance Version (optional)

Servos

(2x) 9g metal gear (4x) 9g standard

Landing Gear Electric retracts with metal trunions

Required Battery

4S 14.8V 2650mAh - 4000mAh Li-Po with T connector

Required Radio

6+ Channel 2.4GHz

Ailerons Yes

Elevator

Yes

Rudder Yes

Flaps

Split Flaps

Lights

No

Hinge Type

Nylon and Foam hinges

Material EPO Foam
Skill Level Intermediate
Build Time 2 Hours
Recommended Environment Outdoor, minimum 200 foot runway, pavement recommended, less than 1" tall smooth grass
